NOTE: This is a Pre-order product. This product will be ready for delivery by the 1st or 2nd week of March 2020. The prices you see are special prices for Pre-order only.

Specification Of the AT10II Transmitter:
● Frequency: 2.4GHz ISM band(2400MHz to 2485MHz)
● Modulation Mode: QPSK
● Channel Bandwidth:5.0MHz
● Spread Spectrum: DSSS,FHSS
● Adjacent Channel Rejection: >38dBM
● Transmitter Power: <100mW(PCB testing),<20dBm(3 meter air testing)
● Operating Voltage: 8.6~15V
● Operating Current: <95mA
● Control Distance: 800 meters ground
● Channel: 10 Channel
● Simulator Mode: Under the simulator model the transmitter action turn off, change to power saving model
● Screen : 16 colorful screen
                Size 78 x 52mm
                Size 78 x 52mm
● Compatible Model: Include all 120 degree and 90 degree swashplate helicopter,all fix wing and glider, five flying model.
● Size: 18 x 9.5 x 22cm
● Weight: 0.95kg

Specification Of R12DS Receiver:
● Frequency: 2.4GHz
● Channel: 12CH,support SBUS and PWM signal output
● Working Voltage: 4.8-10V
● Working Current: 38-45mA(input voltage: 5V)
● Dimension: 50x31.5x14.5mm
● Weight: 14g
● Control Range: About 4KM air (Maximum range tested in unobstructed areas free of interference and may vary depending on local regulations).

Two signal working mode of R12DS:
● PWM signal output working mode: red LED indicates PWM signal output, 11 channels Totally.
● S-BUS signal output working mode: blue/purple LED indicates S-BUS signal output, 12 channels totally.

S-BUS and PWM signal working at the same time. S-BUS signal channel(3 pin of row 11) output 12 channels S-BUS signal, PWM signal channels(3 pin of row 1 to row 10) output CH3 to CH12 PWM signals, but 12 channel in total. How many PWM signal channels you can use depends on how many S-BUS signal channels you have used(e.g: you have use 4 S-BUS signal channels, then you have 8 PWM signal channels to use).

How to match code with transmitter:
● Put the transmitter and the receiver close to each other within 1 meters.
● Turn on the transmitter, then power on the R12DS.
● Connect CH3 of R12DS to ESC.
● There is a black button on the R12DS, use a thin stick press the button twice in two seconds, receiver light starts blinking, after about blinking 8 times, match code success and receiver signal LED always on.

Features:
● Upgraded version of Radiolink AT10,with DSSS and FHSS dual signal
● Higher accuracy of anti-interference and transmitter control bars than AT10.
● Support English & Chinese Menu
● Multiple function remote control system
● Including helicopter,airplane and slider three type flying machine and five models,cover almost every popular model,you can fly any model by this radio.
● 3.5 inch colorful screen 320×480 resolution,clear display menu and graphs.
● Fast response time only 3ms to the operation,faster then the other transmitter 20ms,even ten channels also let you feel it.
● High channel resolution reaches 4096,0.25us per resolution let all the servos keep tranquil.
● Strong anti-jumping,DSSS(Direct sequence spread spectrum) technology.
● Receiver integrate telemetry sensor including signal strength and voltage.
● Support extended engine voltage telemetry module PRM-01 can feedback GPS info, Speed, voltage etc. on AT10II display when work with flight controller APM or PIX.

Note: The AT10II transmitter is NOT compatible with R10D receiver.

Package includes:
● Transmitter
● Receiver
● PRM-01 with cable (Module for Model Voltage Return)
● Throttle-Stick Retainer(Allows the throttle to return to the neutral/center position automatically)
● Instruction Manual
