Aeolian XP-80A Brushless Speed Controller
Fully programmable 80 Amp (100Amp burst) electronic speed controller for brushless electric motors.

Features:
● Equipped with high-speed, small-sized, multifunctional MCU
● Full protection feature including low-voltage protection, over-heat protection, signal lost protection, safe power on protection.
● Excellent startup performance, great throttle linear and quick throttle response excellent low-speed performance.
● Max speed: 240,000 RPM (2 poles), 80,000 RPM (6 poles), 40,000 RPM (12 poles).
● Individual power circuit for MCU and BEC to improve anti-interference capacity.
● The parameters of ESC can be configured via transmitter or programming card.
● Throttle range can be configured to be compatible with different receivers.

Specification:
● Input voltage: 5.5V-22.2V (support 2-6S lithium batteries)
● Continuous current: 80A
● Burst current: 100A (10 seconds)
● BEC output: 3A/5V (switch)
● Suitable for aircraft and helicopters
● Size: 63x28x18mm
● Weight: 60g
● Supplied in Anti-static bag with instruction sheet

Package Contents
● 1 No: Aeolian 80 Amp ESC
