Avionic NEO Silver 3548 KV900

SKU: RZ04954

Current rating is 0.00. Total votes 0.

View / Write review

Mount set is not available only motor.
Introducing Avionic PRO series of brushless motors.
Made from the highest quality magnets, casing and bearings this at the best available quality of motors at such a great value in the market till date.
These motors are specifically designed keeping in mind on how to get the maximum torque at the most optimal RMP and are made for RC controlled models only and will last for more than what your RC model asks for.

Specification:
● Stator Diameter: 28.0 mm(1.102 in)
● Stator Thickness: 28.0 mm(1.102 in)
● No. of Stator Arms: 12
● No. of Magnet Poles: 10
● Motor Wind: 5 Turn D
● Motor Kv: 900 RPM / Volt
● No-Load Current (Io): 2.4 Amps @ 10 volts
● Max Continuous Current: 42 Amps
● Max Continuous Power: 750 Watts
● Weight: 160 Grams(5.65oz)
● Outside Diameter: 34.8 mm(1.37 in)
● Shaft Diameter: 4.0 mm(0.157 in)
● Body Length: 48.0 mm(0.157 in)
● Overall Shaft Length: 67 mm(2.63 in)
● Max LiPo Cell: 3-6 S
● Motor Timing: 5°
● Drive Frequency: 8kHz

LOAD TEST REPORT

Voltage/V	PROP	PULL/g	ESC
(3 cell) 11.1	9*4.5 E	750	40A
(3 cell) 11.1	10*7 E	950	40A
(3 cell) 11.1	11*7 E	1100	40A
(3 cell) 11.1	12*6 E	1600	40A
(3 cell) 11.1	12*3.8 SF	1650	40A

(4 cell) 14.8	9*4.5 E	1250	80A
(4 cell) 14.8	10*7 E	1600	80A
(4 cell) 14.8	11*7 E	1800	80A
(4 cell) 14.8	12*6 E	2250	80A
(4 cell) 14.8	12*3.8 SF	2300	80A

(6 cell) 22.2	9*4.5 E	2400	80A
(6 cell) 22.2	10*7 E	2700	80A
(6 cell) 22.2	11*7 E	2900	80A
(6 cell) 22.2	12*6 E	4000	80A
(6 cell) 22.2	12*3.8 SF	4500	80A
